| 系列标题 | 功率 (W) | 输入电压 (VDC) |
输出电压 (VDC) |
输出路数 | 隔离电压 (VDC) |
封装形式 | 封装尺寸 (mm) |
|
| LM25-23Bxx | 25 | 85~305VAC/100~430VDC | 3.3,5,12,15,24,48 | 1 | 4000VAC | 机壳型 | 80.00*55.00*25.00 | |
| LM15-23Bxx | 15 | 85~305VAC/100~430VDC | 3.3,5,12,15,24,48 | 1 | 4000VAC | 机壳型 | 65.00*55.00*25.00 | |
| LM200-10Bxx | 200 | 90~132/180~264VAC | 5,12,15,24,36,48 | 1 | 3000VAC | 机壳型 | 179.00*99.00*30.00 | |
| LM600-12Bxx | 600 | 176~264VAC/240~373VDC | 12,15,24,36,48 | 1 | 3000VAC | 机壳型 | 220.00*106.00*40.00 | |
| LM450-12Bxx | 450 | 176~264VAC/240~373VDC | 12,15,24,48 | 1 | 3000VAC | 机壳型 | 215.00*115.00*30.00 | |
| LM100-22Bxx | 100 | 165~264VAC/180~373VDC | 5,12,15,24,36,48 | 1 | 4000VAC | 机壳型 | 129.00*97.00*30.00 | |
| LM100-20Bxx | 100 | 85~264VAC/120~373VDC | 5,12,15,24,36,48 | 1 | 4000VAC | 机壳型 | 129.00*97.00*30.00 | |
| LM100-10Dxx | 100 | 90~264VAC/120~373VDC | 5,12,24 | 2 | 3000VAC | 机壳型 | 159.00*97.00*30.00 | |
| LM100-10Cxx | 100 | 90~264VAC/120~373VDC | 5,12,15,24 | 3 | 3000VAC | 机壳型 | 159.00*97.00*30.00 | |
| LM75-10Dxx | 75 | 85~264VAC/120~373VDC | 5,12,24 | 2 | 3000VAC | 机壳型 | 129.00*97.00*30.00 | |
| LM75-10Cxx | 75 | 85~264VAC/120~373VDC | 5,12,15,24 | 3 | 3000VAC | 机壳型 | 129.00*97.00*30.00 | |
| LM50-10Dxx | 50 | 85~264VAC/120~373VDC | 5,12,24 | 2 | 3000VAC | 机壳型 | 99.00*97.00*30.00 | |
| LM50-10Cxx | 50 | 85~264VAC/120~373VDC | 5,12,15,24 | 3 | 3000VAC | 机壳型 | 99.00*97.00*30.00 | |
| LM35-10Dxx | 35 | 85~264VAC/120~373VDC | 5,12,24 | 2 | 3000VAC | 机壳型 | 99.00*97.00*30.00 | |
| LM35-10Cxx | 35 | 85~264VAC/120~373VDC | 5,12,15,24 | 3 | 3000VAC | 机壳型 | 99.00*97.00*30.00 | |
| LM350-10Bxx | 350 | 90~132/180~264VAC | 5,12,15,24,36,48 | 1 | 3000VAC | 机壳型 | 215.00*115.00*30.00 | |
| LM350-12Bxx | 350 | 176~264VAC/240~373VDC | 5,12,15,24,36,48 | 1 | 3000VAC | 机壳型 | 215.00*115.00*30.00 | |
| LM150-22Bxx | 150 | 165~264VAC/180~373VDC | 5,12,15,24 | 1 | 4000VAC | 机壳型 | 159.00*97.00*30.00 | |
| LM150-20Bxx | 150 | 85~264VAC/120~373VDC | 5,12,15,24 | 1 | 4000VAC | 机壳型 | 159.00*97.00*30.00 | |
| LM75-22Bxx | 75 | 165~264VAC/180~373VDC | 5,12,15,24 | 1 | 4000VAC | 机壳型 | 99.00*97.00*30.00 | |
| LM75-20Bxx | 75 | 85~264VAC/120~373VDC | 5,12,15,24 | 1 | 4000VAC | 机壳型 | 99.00*97.00*30.00 | |
| LM50-22Bxx | 50 | 165~264VAC/180~373VDC | 5,12,15,24 | 1 | 4000VAC | 机壳型 | 99.00*82.00*30.00 | |
| LM50-20Bxx | 50 | 85~264VAC/120~373VDC | 5,12,15,24 | 1 | 4000VAC | 机壳型 | 99.00*82.00*30.00 | |
| LM35-22Bxx | 35 | 165~264VAC/180~373VDC | 5,12,15,24 | 1 | 4000VAC | 机壳型 | 99.00*82.00*30.00 | |
| LM35-20Bxx | 35 | 85~264VAC/120~373VDC | 5,12,15,24 | 1 | 4000VAC | 机壳型 | 99.00*82.00*30.00 |
