| 系列标题 | 功率 (W) | 输入电压 (VDC) |
输出电压 (VDC) |
输出路数 | 隔离电压 (VDC) |
封装形式 | 封装尺寸 (mm) |
|
| RSP-500 | 500 | 85~264VAC/120-370VDC | 3.3,5,12,15,24,27,48 | 1 | 3000VAC | 机壳型 | 230*127*40.5 | |
| RSP-320 | 320 | 88~264VAC/124-370VDC | 2.5,3.3,5,7.5,12 | 1 | 3000VAC | 机壳型 | 215*115*30 | |
| RSP-200 | 200 | 88~264VAC/124-370VDC | 3.3,5,12,15,24,27,48 | 1 | 3000VAC | 机壳型 | 215*115*30 | |
| RSP-150 | 150 | 85~264VAC/120-370VDC | 3.3,5,12,15,24,27,48 | 1 | 3750VAC | 机壳型 | 199*99*30 | |
| RSP-100 | 100 | 85~264VAC/120-370VDC | 3.3,5,12,15,24,27,48 | 1 | 3750VAC | 机壳型 | 179*99*30 | |
| RSP-75 | 75 | 85~264VAC/120-370VDC | 3.3,5,12,15,24,27,48 | 1 | 3750VAC | 机壳型 | 159*97*30 |
