| 系列标题 | 功率 (W) | 输入电压 (VDC) |
输出电压 (VDC) |
输出路数 | 隔离电压 (VDC) |
封装形式 | 封装尺寸 (mm) |
|
| EPP-400 | 400 | 80~264VAC/113-370VDC | 12,15,24,27,48 | 1 | 3000VAC | 裸板 | 127*76.2*35 | |
| EPP-300 | 300 | 90~264VAC/127-370VDC | 12,15,24,27,48 | 1 | 3000VAC | 裸板 | 127*76.2*35 | |
| EPP-200 | 200 | 80~264VAC/113-370VDC | 12,15,24,27,48 | 1 | 3000VAC | 裸板 | 101.6*50.8*29 | |
| EPP-150 | 150 | 90~264VAC/127-370VDC | 12,15,24,27,48 | 1 | 3000VAC | 裸板 | 101.6*50.8*29 | |
| EPP-100 | 100 | 90~264VAC/127-370VDC | 12,15,24,27,48 | 1 | 3000VAC | 裸板 | 101.6*50.8*29 | |
| ELP-75 | 75 | 90~264VAC/127-370VDC | 3.3,5,12,15,24,36,48 | 1 | 3000VAC | 裸板 | 175*60*27 | |
| EPS-120 | 120 | 80~264VAC/113-370VDC | 12,15,24,27,48 | 1 | 3000VAC | 裸板 | 101.6*50.8*29 | |
| EPS-65 | 65 | 90~264VAC/127-370VDC | 3.3,5,12,15,24,36,48 | 1 | 3000VAC | 裸板 | 101.6*50.8*29 | |
| EPS-45 | 45 | 85~264VAC/120-370VDC | 3.3,5,12,15,24,36,48 | 1 | 3000VAC | 裸板 | 101.6*50.8*29 | |
| EPS-35 | 35 | 85~264VAC/120-370VDC | 3.3,5,12,15,24,27,36,48 | 1 | 3000VAC | 裸板 | 76.2*50.8*24 | |
| EPS-25 | 25 | 85~264VAC/120-370VDC | 3.3,5,12,15,24,27,36,48 | 1 | 3000VAC | 裸板 | 76.2*50.8*24 | |
| EPS-15 | 15 | 85~264VAC/120-370VDC | 3.3,5,12,15,24,27,36,48 | 1 | 3000VAC | 裸板 | 63.5*45.7*24 |
